IR Control 8
Advanced Infrared Extender Set
 "IR Control 8 - Advanced Infrared Extender Set")
 "Can we advise you?")
- Operate all your A/V equipment that is out of sight.
- Operate 4 (max. 8) A/V devices behind closed cupboard doors (or even from another room) with your current remote control.
- New interference-suppressing technology for use in the vicinity of Flat Screens (such as Plasma, LCD and LED screens), indirect sunlight and energy-saving light bulbs.
- Works with almost every brand and model and is suitable for the new IR code formats (such as RC-MM) which are being used in a great deal of new HD equipment.
- With the IR Control8 you can immediately operate 4 pieces of equipment. With Marmitek ‘IRCP blinking 2 LED‘, an infrared extension cable, you can connect another 2 x 2 pieces of equipment.
- With the exception of the small IR receiver, the complete set can be located out of sight.
- Compatible with Sky, Sky+ and SkyHD.
How does the IR Control 8™ work?
Locate your A/V equipment in a closed cupboard, TV cabinet or even in another room. The IR receiver must be installed in view of your own remote control. This new, updated IR receiver can even be placed in the vicinity of your Flat Screen (Plasma, LCD or LED screen). Stick the IR LEDs onto the front panel of your A/V equipment and place the IR main module out of sight. Point the remote control at the IR receiver in order to send the appropriate command to the IR LEDs (via the IR main module). These will then immediately pass this onto the A/V equipment.
 "Click here for more product photos")
FCPDL IR Control 8 (PDF 0.26 MB)
 "Set includes - IR Control 8")
IRCP blinking 2 LED
Extra IR Extension cable blinking 2 LED
- With the help of an extra IR extension cable you can operate 2 extra A/V devices.
- The blinking LED version lights up if you send an infrared command with the remote control.
)
IR Receiver 3856S
Extra Dual-band IR Receiver (surface mount)
- You can use an extra IR Receiver to operate your A/V equipment from another room.
- New, disruption-suppressing technology for use in the vicinity of Flat Screens (such as Plasma, LCD and LED screens), direct sunlight and energy-saving bulbs.
/website_product_IR Receiver 3856S.jpg&action=resize(130x130))
IR Receiver 3856P
Extra Dual-band IR Receiver (panel mount)
- You can use an extra IR Receiver to operate your A/V equipment from another room.
- New, disruption-suppressing technology for use in the vicinity of Flat Screens (such as Plasma, LCD and LED screens), direct sunlight and energy-saving bulbs.
/website_product_IR Receiver 3856P.jpg&action=resize(130x130))
UG 124x176mm IR CONTROL 8 (PDF 0.71 MB)
 "Technical specifications - IR Control 8")
IR Control 8 gebruikersreview op unexpected.be
)
(Dutch)
){kind=link}
){kind=link}
){kind=link}
){kind=link}
){kind=link}
){kind=link}
Do not remove any of the LEDs. You can, however, attach the unused LED to the bottom or back of the device.
If the LED does turn red, then you should check the following points:
- Has the LED been installed at the right place? Sometimes it is difficult to determine at which spot exactly, the infrared receiver of your device is situated. Sometimes you can determine this by pointing your remote control at the device. The infrared receiver must be in the area where the LED lights up.
- Has the connector plug been inserted deep enough?
- Is the original attachment-tape still on the backside of the infrared eyes? This is a special infrared-permeable tape. By replacing it with a standard attachment-tape, it may possibly stop working.
- Is the cable damaged possibly?
If the LED does turn red, then you should check the following points:
- Has the LED been installed at the right place? Sometimes it is difficult to determine at which spot exactly, the infrared receiver of your device is situated. Sometimes you can determine this by pointing your remote control at the device. The infrared receiver must be in the area where the LED lights up.
- Has the connector plug been inserted deep enough?
- Is the original attachment-tape still on the backside of the infrared eyes? This is a special infrared-permeable tape. By replacing it with a standard attachment-tape, it may possibly stop working.
- Is the cable damaged possibly?
Is your question still unanswered? Click here for a detailed support request.
| Art.no. | Plugtypes | ||||||||
| 09891 | Europlug | ||||||||
| 09892 | UK plug | ||||||||
